Vitrek V76 Hipot Tester

Overview

The Vitrek V76 is a compact hipot tester from the V7X Series, designed for electrical safety testing with color touch LCD and high-speed DSP technology. It delivers 2500 VAC and 2750 VDC output with built-in switching for up to 8 channels of high voltage, 8 channels of return, and 8 channels of continuity testing.

Made in the USA to meet UL, CSA, TUV, and IEC hipot requirements, the V76 provides accuracy, speed, and reliability with insulation resistance measurement to 450GΩ and leakage current measurement to 100 nano-amps.

Key Features

• 2500 VAC and 2750 VDC hipot output
• 8-channel switching (8 HV, 8 return, 8 continuity channels)
• Insulation resistance measurement to 450GΩ
• Leakage current measurement to 100 nano-amps
• Color touch LCD interface with user-friendly design
• Test memory stores up to 999 steps and 60 test sequences
• 150µS safety shutdown with ramped discharge capability
• USB, RS232, and Digital I/O interfaces
• Internal self-test function
• 2-year warranty

Applications

• Production line safety testing
• Medical device manufacturing
• Electronics manufacturing
• Multi-channel high-voltage testing environments

Included Accessories

• TL-209 probe
• Power cord
• Operating manual
• QTPro-7 software (45-day free trial)
• NIST traceable calibration certificate
