Vitrek V71 Hipot Tester
Request a quote
Vitrek V71 AC/DC Hipot Tester with 5 kVAC/DC output, color touch LCD, leakage current to 100 nanoamps, and insulation resistance to 450GΩ.
Product details
| Model | V71 |
| Manufacturer | Vitrek |
| Category | Hipot Testers |
| Availability | Made to order |
Description
Overview
The Vitrek V71 is an AC/DC electrical safety (hipot) tester from the V7X series, offering both alternating and direct current testing capabilities. Designed and manufactured in the USA to meet UL, CSA, TUV, and IEC standards, it combines high-speed DSP technology with a color touch LCD interface in a compact, fan-free design suitable for diverse production line applications.
Key Features
- AC and DC Hipot testing to 5 kVAC/DC
- Leakage current measurement to 100 nanoamps
- Insulation resistance testing to 450GΩ
- Ground continuity testing to 30 amps
- Color touch LCD with high-speed DSP processor
- Test memory: up to 999 steps and 60 sequences
- Internal self-test with automatic current verification
- 150µS safety shutdown
- Ramped discharge capability
- USB, RS232, and Digital I/O connectivity
- 2-year warranty
- Made in the USA (San Diego, CA)
Applications
- Production line electrical safety testing for AC and DC equipment
- UL, CSA, TUV, and IEC standard verification
- Insulation and leakage current assessment
- Battery and DC power supply testing
Included Accessories
- TL-209 Test Lead Kit
- Power Cord
- Operating Manual
- QTPro-7 Software (45-day evaluation)
- NIST Traceable Calibration Certificate
Specifications
| AC Voltage | 5 kV |
| DC Voltage | 5 kV |
| Insulation Resistance Range | 450 G |
| Series | V7X Series |
| Function | AC, DC, LR |
