Vitrek V70 Hipot Tester
Request a quote
Vitrek V70 AC Hipot Tester with 5 kVAC output, color touch LCD, leakage current measurement to 100 nanoamps, and insulation resistance to 450GΩ.
Product details
| Model | V70 |
| Manufacturer | Vitrek |
| Category | Hipot Testers |
| Availability | Made to order |
Description
Overview
The Vitrek V70 is an AC-only electrical safety (hipot) tester from the V7X series, purpose-built for production line compliance testing. Designed and manufactured in the USA, it meets UL, CSA, TUV, and IEC standards with high-speed DSP technology and a color touch LCD interface in a compact, fan-free design.
Key Features
- AC Hipot testing to 5 kVAC
- Leakage current measurement to 100 nanoamps
- Insulation resistance testing to 450GΩ
- Ground continuity testing to 30 amps
- Color touch LCD with high-speed DSP processor
- Test memory: up to 999 steps and 60 sequences
- Internal self-test with automatic current verification
- 150µS safety shutdown
- Ramped discharge capability
- USB, RS232, and Digital I/O connectivity
- 2-year warranty
- Made in the USA (San Diego, CA)
Applications
- Production line electrical safety compliance testing
- UL, CSA, TUV, and IEC standard verification
- Insulation and leakage current assessment
Included Accessories
- TL-209 Test Lead Kit
- Power Cord
- Operating Manual
- QTPro-7 Software (45-day evaluation)
- NIST Traceable Calibration Certificate
Specifications
| AC Voltage | 5 kV |
| DC Voltage | NA |
| Insulation Resistance Range | 450 G |
| Series | V7X Series |
| Function | AC, LR |
