Rohde & Schwarz RTH1012 Handheld Oscilloscope Package
Request a quote
Rohde & Schwarz RTH1012 is a 2-channel handheld oscilloscope package with 100 MHz bandwidth, integrated digital multimeter, and CAT IV 600V isolated inputs.
Product details
| Model | RTH1012 |
| Manufacturer | Rohde & Schwarz |
| Category | Handheld Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz RTH1012 is a 2-channel handheld digital oscilloscope package configured with 100 MHz bandwidth. This portable oscilloscope combines laboratory performance with rugged field-ready construction, featuring isolated channels, integrated digital multimeter, and comprehensive measurement capabilities for both lab debugging and field troubleshooting.
Key Features
- 2-channel oscilloscope with 100 MHz bandwidth and 5 Gsample/s sampling rate
- Isolated channels with CAT IV 600V rating for safe measurements
- 33 automatic measurement functions for signal analysis
- 50,000 waveforms per second for rapid fault detection
- Integrated digital multimeter for additional measurement versatility
- 2 mV/div to 100 V/div sensitivity with up to 300 V offset range
- Deep zoom with 500 ksample acquisition memory
- Battery-powered for portable field operation
Applications
- Electronic troubleshooting and signal analysis
- Embedded system debugging and development
- Field measurements and equipment maintenance
- Power supply analysis and verification
Included Accessories
- 500 MHz 10:1 600V CAT IV voltage probe for each input channel
- Power supply with plugs for EU, GB, and US
- Lithium-ion battery pack
- Soft carrying handle
Specifications
| Bandwidth | 100 MHz |
| Analog Channels | 2 |
| Sampling Rate | 5 GS/s |
| Memory | 2 Mpts |
| Display Type | 7.0 WVGA LC TFT |
| Series | RTH Series |
| Alternate Product Number | 1317.5000P12 |
| Type | Handheld |
