Fluke FLUKE-190-102-III-S Handheld Oscilloscope
Request a quote
Fluke FLUKE-190-102-III-S 100 MHz 2-channel oscilloscope with 1.25 GS/s sampling, integrated DMM, SCC-293 kit with carrying case and Wi-Fi adapter, CAT III/IV rated for field diagnostics.
Product details
| Model | FLUKE-190-102-III-S |
| Manufacturer | Fluke |
| Category | Handheld Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Fluke 190-102-III-S ScopeMeter is a high-performance portable oscilloscope engineered to withstand harsh industrial environments. It features two fully isolated channels with 100 MHz bandwidth and 1.25 GS/s sampling rate, delivering bench-class performance in a field-portable format. The complete SCC-293 kit includes protective carrying case, FlukeView software, and Wi-Fi dongle for comprehensive field and remote diagnostics.
Key Features
- 2 fully isolated channels with 100 MHz bandwidth and 3.5 ns rise time
- 1.25 GS/s real-time sampling rate with 10,000 samples per channel memory
- Integrated 5,000-count Digital Multimeter for dual-purpose measurements
- CAT III 1000V / CAT IV 600V safety rating for hazardous environments
- IP51 dust and drip-proof rating for rugged field conditions
- 100-screen Replay function and FFT frequency spectrum analysis
- SCC-293 kit: CXT293 carrying case, FlukeView software, DWA-131 Wi-Fi dongle
- VPS421 100:1 probes for safe high-voltage measurements
Applications
- Industrial machinery installation and commissioning
- Automation and process control systems
- Power electronics testing and analysis
- Field troubleshooting and preventive maintenance
- Remote monitoring with Wi-Fi and PC connectivity
Included Accessories
- ScopeMeter 190-102-III unit
- BC190/830 power adapter with cord set
- BP290 Li-ion battery pack
- VPS421 probe (2x)
- TL175 test lead set
- CXT293 protective carrying case
- DWA-131 Wi-Fi dongle
- FlukeView software activation code
- USB cable, hand and hanging straps
Specifications
| Bandwidth | 100 MHz |
| Analog Channels | 2 |
| Sampling Rate | 1.25 GS/s |
| Series | 190 Series III |
| Alternate Product Number | 5282379 |
| Type | Handheld |
| Vertical Resolution | 8 bit |
