Teledyne LeCroy T3AFG40 Arbitrary Function Generator
Request a quote
Teledyne LeCroy T3AFG40 is a 40 MHz dual-channel arbitrary function generator with 1.2 GS/s sampling rate, 8 Mpts memory, 16-bit resolution, and multiple modulation capabilities.
Product details
| Model | T3AFG40 |
| Manufacturer | Teledyne LeCroy |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The Teledyne LeCroy T3AFG40 is a dual-channel arbitrary function generator offering excellent performance for mid-range test and measurement applications. With 40 MHz maximum bandwidth, 1.2 GS/s sampling rate, and 8 Mpts of memory per channel, it delivers high-quality waveforms with 16-bit vertical resolution. The proprietary Arbitrary & Pulse techniques provide reliable signal generation for arbitrary, square, and pulse waveforms in analog and digital circuit testing.
Key Features
- 40 MHz maximum bandwidth with 1.2 GS/s sampling rate
- 8 Mpts deep memory per channel for versatile waveforms
- 16-bit vertical resolution for accurate signal generation
- Dual-channel simultaneous output
- Wide range of modulation types: AM, DSB-AM, FM, PM, FSK, ASK, PWM, Sweep, Burst, and PSK
- Built-in and user-defined arbitrary waveforms
Applications
- Analog and digital circuit development and testing
- Telecommunications equipment validation
- Signal processing and filter design
- Industrial electronics testing and troubleshooting
Specifications
| Frequency | 40 MHz |
| Sampling Rate | 1.2 GS/s |
| Number of Channels | 2 Channel |
| Memory | 8 Mpts |
| Series | T3AFG Series |
