Teledyne LeCroy T3AFG30 Arbitrary Function Generator
Request a quote
Teledyne LeCroy T3AFG30 is a 30 MHz dual-channel arbitrary function generator with 150 MS/s sampling rate, 16 kpts memory per channel, and 14-bit resolution for compact laboratory applications.
Product details
| Model | T3AFG30 |
| Manufacturer | Teledyne LeCroy |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The Teledyne LeCroy T3AFG30 is a dual-channel function and arbitrary waveform generator designed for educational and entry-level industrial applications. Offering 30 MHz maximum bandwidth with 150 MS/s sampling rate and 16 kpts of memory per channel, it provides cost-effective signal generation with 14-bit vertical resolution. The proprietary Arbitrary & Pulse techniques enable reliable generation of arbitrary, square, and pulse waveforms.
Key Features
- 30 MHz maximum bandwidth with 150 MS/s sampling rate
- 16 kpts deep memory per channel
- 14-bit vertical resolution for signal accuracy
- Dual-channel simultaneous output
- Multiple modulation types: AM, DSB-AM, FM, PM, FSK, ASK, PWM, Sweep, Burst, and PSK
- Built-in and user-defined arbitrary waveforms
Applications
- Electrical engineering education and laboratory training
- Audio and signal processing development
- General-purpose circuit testing and prototyping
- Basic RF and analog circuit validation
Specifications
| Frequency | 30 MHz |
| Sampling Rate | 150 MS/s |
| Number of Channels | 2 Channel |
| Memory | 16 kpts |
| Series | T3AFG Series |
