Siglent SDG2122X Function/Arbitrary Waveform Generator
Request a quote
A dual-channel function and arbitrary waveform generator offering 120 MHz bandwidth, 20 Vpp output amplitude, and 1.2 GSa/s sampling rate for flexible signal generation.
Product details
| Model | SDG2122X |
| Manufacturer | Siglent |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The Siglent SDG2122X is a dual-channel function and arbitrary waveform generator designed for flexible signal generation in educational and professional applications. It delivers up to 120 MHz bandwidth with high-fidelity output, 16-bit vertical resolution, and advanced waveform synthesis capabilities.
Key Features
- Dual-channel design with 120 MHz maximum output frequency
- 20 Vpp maximum output amplitude with 80 dB dynamic range
- 1.2 GSa/s sampling rate with 16-bit vertical resolution
- TrueArb technology supports arbitrary waveforms from 8 to 8 million points at sampling rates of 1 μSa/s to 75 MSa/s
- EasyPulse technology for low-jitter square and pulse waveforms with precise pulse width and rise/fall time adjustment
- Analog and digital modulation: AM, DSB-AM, FM, PM, FSK, ASK, PWM
- Sweep and Burst functions
- High-precision frequency counter
- 4.3-inch touch screen display
- Standard interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11); optional GPIB
Included Accessories
- Quick Start Guide
- Product Certification
- Power Cord
- USB Cable
- BNC Coaxial Cable
- CD with Quick Start, datasheet, and Application Software Package
- Calibration Certificate
Specifications
| Frequency | 120 MHz |
| Number of Channels | 2 Channel |
| Memory | 8 Mpts |
| Series | SDG2000X Series |
