RIGOL DSG815 RF Signal Generator
Request a quote
RIGOL DSG815 RF signal generator covers 9 kHz to 1.5 GHz with +20 dBm output power, -105 dBc/Hz phase noise, and complete AM/FM/PM modulation.
Product details
| Model | DSG815 |
| Manufacturer | RIGOL |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The RIGOL DSG815 is a compact RF signal generator in the DSG800 series, delivering economical signal sources with full frequency and power sweep capability. It covers 9 kHz to 1.5 GHz with outstanding performance in a small footprint, making it ideal for educational laboratories, industrial production lines, and research applications.
Key Features
- Frequency range: 9 kHz to 1.5 GHz
- Low phase noise: up to -105 dBc/Hz (typical)
- High output power: up to +20 dBm (typical)
- Amplitude accuracy: 0.5 dB (typical)
- Complete AM/FM/PM analog modulation
- Flexible frequency and amplitude sweep functions
- Powerful pulse modulation
- Standard LF output function
- Vector modulation capability
- System flatness calibration
- Compact design with superior portability
Applications
- Educational laboratory demonstrations and training
- Industrial production line testing
- Development and research applications
- RF system verification and validation
Specifications
| Maximum Frequency | 1.5 GHz |
| Frequency Range | 0.5 - 4.0 |
| Series | DSG800 Series |
