GW Instek AFG-4260 60MHz 2-Channel Arbitrary Function Generator
GW Instek AFG-4260 is a 60MHz dual-channel arbitrary function generator with 500MSa/s sample rate, 16-bit resolution, 10M memory depth, and advanced modulation capabilities.
Product details
| Model | AFG-4260 |
| Manufacturer | GW Instek |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The GW Instek AFG-4260 is a dual-channel arbitrary function generator offering 60MHz bandwidth with high-resolution signal generation. Featuring an 8-inch touch-screen display, 500MSa/s sample rate, and 10M memory depth per channel, it supports 146 built-in arbitrary waveforms and advanced modulation functions including AM, DSB-AM, FM, PM, PWM, and various FSK and PSK modes. The dual-channel architecture enables frequency coupling, amplitude coupling, and phase tracking for synchronized multi-channel applications.
Key Features
- 60MHz dual-channel output with 500MSa/s sample rate
- 16-bit amplitude resolution with 1µHz minimum frequency resolution
- 10M memory depth per channel with 146 built-in arbitrary waveforms
- Comprehensive modulation: AM, DSB-AM, FM, PM, PWM, ASK, PSK, BPSK, QPSK, FSK, 3FSK, 4FSK, OSK, SUM
- Built-in sweep, burst, and counter functions
- 8-inch high-resolution TFT LCD display with multi-touch screen
- Dual-channel coupling: frequency coupling, amplitude coupling, and phase tracking
- USB and LAN interfaces for remote operation and waveform editing
Applications
- Educational institutions and training programs
- Automotive electronics testing and development
- Electronic product design and component testing
Included Accessories
- 2x BNC to alligator clips test leads
- USB cable
- Power cord
Specifications
Request a quote
