GW Instek AFG-3081 80MHz Arbitrary Function Generator
Request a quote
GW Instek AFG-3081 is an 80MHz arbitrary waveform generator with 200MSa/s sample rate, 16-bit resolution, and 1M memory depth for industrial and research applications.
Product details
| Model | AFG-3081 |
| Manufacturer | GW Instek |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The GW Instek AFG-3081 is an 80MHz arbitrary waveform generator designed for industrial, scientific research, and educational applications. It features a 16-bit resolution, 200MSa/s sample rate, and 1M memory depth for editing arbitrary waveforms through an intuitive user interface. The Direct Waveform Reconstruction (DWR) function enables users to import waveforms directly from GW Instek GDS-2000 Series oscilloscopes via USB, streamlining measurement workflows.
Key Features
- Wide frequency range from 1µHz to 80MHz
- High 200MSa/s sampling rate with 16-bit amplitude resolution
- 1M-point memory depth for arbitrary waveforms
- 4.3-inch high-resolution TFT LCD display with on-screen help
- Switchable 50 Ohm and Hi-Z impedances
- Multiple waveform input methods: front panel operation, CSV file upload, Direct Waveform Reconstruction, and PC software
- USB, RS-232, and GPIB interfaces for PC control and IEEE488.2 commands
Applications
- Educational institutions and training
- Scientific research and development
- Industrial testing and measurement
Included Accessories
- Instruction manual
- Test lead
- Power cord
Specifications
| Channel/Port Count | 1 |
| High Frequency (range) | 10MHz <= 100MHz |
| Frequency | 80 MHz |
| Number of Channels | 1 Channel |
| Series | AFG-3000 Series |
