GW Instek AFG-2012 12MHz Arbitrary Function Generator
Request a quote
GW Instek AFG-2012 — 12MHz DDS-based arbitrary function generator with 20 MSa/s sampling rate, 10-bit resolution, 4k-point memory, and USB control interface for waveform editing.
Product details
| Model | AFG-2012 |
| Manufacturer | GW Instek |
| Category | Function & Arbitrary Waveform Generators |
| Availability | Made to order |
Description
Overview
The GW Instek AFG-2012 is a 12MHz DDS-based arbitrary function generator designed for educational and industrial applications. It provides flexible waveform generation with a 20 MSa/s sampling rate, 10-bit vertical resolution, and 4k-point memory for arbitrary waveforms. The user-friendly interface allows setting parameters through keypad entry or knob selection, with all settings displayed on a 3.5-inch LCD screen.
Key Features
- Frequency range 0.1 Hz to 12 MHz with 1 Hz resolution
- Multiple waveforms: Sine, Square, Triangular, Noise, and Arbitrary
- 20 MSa/s sampling rate with 10-bit vertical resolution
- 4k-point memory for arbitrary waveform storage
- 1% to 99% adjustable duty cycle for square waveforms
- 3.5-inch LCD screen displays all waveform parameters simultaneously
- USB device interface for remote control and waveform editing
- PC arbitrary waveform editing software included
Applications
- Educational signal generation and experimentation
- Basic industrial testing and measurement
- Filter and amplifier circuit testing
- Signal source for various electronic applications
Included Accessories
- User's manual CD
- Quick Start Guide
- GTL-110 test lead (1 included)
- Power cord
Specifications
| Channel/Port Count | 1 |
| High Frequency (range) | 10MHz <= 100MHz |
| Frequency | 12 MHz |
| Sampling Rate | 20 MS/s |
| Vertical Resolution | 10 bit |
| Series | AFG-2000 Series |
