Teledyne LeCroy WAVESURFER 3104Z PROMO2 Digital Oscilloscope
Request a quote
WaveSurfer 3104Z PROMO2 is a 1 GHz, 4-channel oscilloscope with 10.1-inch capacitive touch screen, MAUI interface, and advanced anomaly detection with history mode and WaveScan.
Product details
| Model | WAVESURFER 3104Z PROMO2 |
| Manufacturer | Teledyne LeCroy |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The WaveSurfer 3104Z PROMO2 is a 1 GHz, 4-channel oscilloscope featuring a large 10.1-inch capacitive touch screen and the advanced MAUI user interface. The instrument provides up to 20 Mpts of memory, full mixed signal capability as standard, multi-instrument functions, and comprehensive analysis tools for design and debug applications.
Key Features
- 1 GHz bandwidth (100 MHz, 200 MHz, 350 MHz, 500 MHz also available)
- Up to 4 GS/s sample rate
- Long memory — up to 20 Mpts
- 10.1-inch capacitive touch screen — 30% larger than competitive offerings
- MAUI interface designed for touch with simplified operation
- 16-channel digital MSO capability (optional)
- Advanced anomaly detection with history mode, WaveScan, and mask testing
- Multi-instrument capabilities: protocol analysis, waveform generation, digital voltmeter, frequency counter
- Upgradeable bandwidth and field-upgradable software and hardware options
Applications
- Power analysis and characterization
- Serial bus protocol debugging
- Embedded systems development and debug
Specifications
| Bandwidth | 1 GHz |
| Analog Channels | 4 |
| Digital Channels | 16 |
| Sampling Rate | 4 GS/s |
| Memory | 10 Mpts |
| Type | DSO |
| Vertical Resolution | 8 bit |
| Display Type | 10.1 Capacitive Color Touch |
| Series | 3000z Series |
| Alternate Product Number | Wavesurfer 3104Z Promo |
