Teledyne LeCroy WAVESURFER 3054Z PROMO1 MSO Oscilloscope
Request a quote
Teledyne LeCroy WAVESURFER 3054Z PROMO1 offers 500 MHz bandwidth, 4-channel operation, 4GS/s sampling, 20 Mpts memory, and a 10.1 inch touch display with all analysis tools included.
Product details
| Model | WAVESURFER 3054Z PROMO1 |
| Manufacturer | Teledyne LeCroy |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Teledyne LeCroy WaveSurfer 3054z PROMO1 is a 500 MHz, four-channel digital oscilloscope engineered for signal analysis and circuit debugging. This promotional bundle includes all software analysis options and an MSO probe as standard equipment, providing comprehensive measurement and mixed-signal analysis capabilities. The unit features a large 10.1 inch capacitive touch screen and 20 Mpts of memory for detailed waveform capture.
Key Features
- 500 MHz bandwidth with field-upgradeable options up to 1 GHz
- Four analog channels with up to 4 GS/s sample rate
- 20 Mpts of acquisition memory
- 10.1 inch capacitive touch display—30% larger viewing area than competitive models
- MAUI user interface designed for intuitive touch operation
- Mixed Signal Oscilloscope (MSO) capability standard—supports 16 digital channels
- Advanced anomaly detection with history mode and WaveScan search functionality
- Multi-instrument capabilities: protocol analysis, function generator, digital voltmeter, frequency counter
- Field-upgradable bandwidth and software/hardware options
- Comprehensive math, measurement, debug, and documentation toolset
Applications
- Digital circuit debugging and verification
- Mixed-signal system design and troubleshooting
- Protocol analysis and serial communication testing
- Research and development signal verification
- Production and quality assurance testing
Included Accessories
- MSO probe for mixed-signal analysis
- Complete analysis software suite
Specifications
| Bandwidth | 500 MHz |
| Analog Channels | 4 |
| Digital Channels | 16 |
| Sampling Rate | 4 GS/s |
| Memory | 10 Mpts |
| Type | MSO |
| Vertical Resolution | 8 bit |
| Display Type | 10.1 Capacitive Color Touch |
| Series | 3000z Series |
