Teledyne LeCroy T3DSO1104HD Digital Oscilloscope
Request a quote
Teledyne LeCroy T3DSO1104HD — 4-channel 100 MHz digital oscilloscope with 2 GSa/s sampling, 12-bit resolution, and 200 Mpts record length.
Product details
| Model | T3DSO1104HD |
| Manufacturer | Teledyne LeCroy |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Teledyne LeCroy T3DSO1104HD is a 4-channel digital oscilloscope with 100 MHz analog bandwidth and 12-bit analog-to-digital converters capable of up to 2 GSa/s sampling. With a maximum record length of 200 Mpts and a large 10.1" capacitive touchscreen display, this oscilloscope is designed for comprehensive waveform capture, detailed analysis, and flexible remote operation over LAN.
Key Features
- 12-bit Analog-Digital Converters with sample rate up to 2 GSa/s
- 70 μVrms noise floor @ 200 MHz bandwidth with 0.5% DC gain accuracy
- 4 analog channels, up to 100 MHz bandwidth
- Waveform capture rate up to 120,000 wfm/s (normal mode), 500,000 wfm/s (sequence mode)
- 256-level intensity grading and color temperature display modes
- Up to 100 Mpts/ch record length
- Intelligent triggering: Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video (HDTV), Qualified, Nth edge, Delay, Setup/Hold time
- Serial bus triggering and decoder supporting I²C, SPI, UART, CAN, LIN, CAN-FD (decode), and FlexRay (decode)
- 16 digital channels (optional)
- History waveform recording with up to 80,000 frames maximum
- Automatic measurements on 50+ parameters with histogram, track, trend, and gating
- 4 Math traces with 2 Mpts FFT and formula editor
- Hardware-based Average, ERES, and Mask Test with Mask Editor
- 25 MHz waveform generator (optional)
- 10.1" capacitive touchscreen with multi-touch gesture support
- Interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11/Telnet/Socket), Pass/Fail, Trigger Out
- Built-in web server with SCPI remote control and external mouse/keyboard support
Applications
- Embedded systems and digital circuit debugging
- Signal integrity and timing analysis
- Serial protocol analysis and decoding
- Power supply and amplifier characterization
- Research and laboratory testing
Included Accessories
- Standard Passive Probe (appropriate to oscilloscope bandwidth) x 4
- USB Cable
- Power Cord
- Quick Start Guide
- Certificate of Calibration
Specifications
| Bandwidth | 100 MHz |
| Analog Channels | 4 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 2 GS/s |
| Memory | 200 Mpts |
| Type | DSO |
| Vertical Resolution | 12 bit |
| Display Type | 10.1 TFT LCD Capacitive Color Touch |
| Series | T3DSO1000HD Series |
| Height | 9.3" |
| Length | 12.5" |
| Width | 6" |
