Teledyne LeCroy T3DSO1102 Digital Oscilloscope
Request a quote
Teledyne LeCroy T3DSO1102 is a 2-channel digital oscilloscope with 100 MHz bandwidth, 1 GSa/s sample rate, 7 Mpts memory, and built-in serial bus triggering and decode.
Product details
| Model | T3DSO1102 |
| Manufacturer | Teledyne LeCroy |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Teledyne LeCroy T3DSO1102 is a 2-channel digital oscilloscope from the T3DSO1000 series, featuring 100 MHz analog bandwidth, 1 GSa/s maximum sample rate, and 7 Mpts of sample memory. Equipped with a 7-inch color display and user-friendly front panel design, it includes free enabled serial bus triggering and decode support for I2C, SPI, UART, RS232, CAN, and LIN protocols. With waveform capture rates up to 400,000 wfm/s in sequence mode, it efficiently captures unusual or low-probability events.
Key Features
- 2-channel analog input with 100 MHz bandwidth
- 1 GSa/s maximum sample rate with 7 Mpts memory
- 400,000 waveform captures per second in sequence mode
- Built-in serial bus triggering and decode (I2C, SPI, UART, RS232, CAN, LIN)
- Advanced math functions: FFT, addition, subtraction, multiplication, division, integration, differentiation, square root
- 256-level intensity grading and color temperature display
- History waveforms and segmented acquisition (up to 80,000 memory segments)
- Gate and zoom measurement capabilities
- 7-inch color display with intuitive front-panel controls
Applications
- Electronics design and debugging
- Signal integrity analysis
- Serial protocol troubleshooting and development
- Production testing and quality assurance
Specifications
| Bandwidth | 100 MHz |
| Analog Channels | 2 |
| Digital Channels | None |
| Sampling Rate | 1 GS/s |
| Memory | 7 Mpts |
| Type | DSO |
| Vertical Resolution | 8 bit |
| Display Type | 7 TFT LCD Color |
| Series | 1000 Series |
