Teledyne LeCroy HDO4034A Digital Oscilloscope
Request a quote
Teledyne LeCroy HDO4034A — 350MHz digital oscilloscope with 12-bit resolution, 10 GS/s sampling, and HD4096 technology for precision measurement and signal analysis.
Product details
| Model | HDO4034A |
| Manufacturer | Teledyne LeCroy |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Teledyne LeCroy HDO4034A is a 350MHz, 4-channel digital oscilloscope featuring 12-bit vertical resolution with HD4096 high definition technology. With 10 GS/s sampling rate and up to 12.5 Mpts memory per channel, it captures and displays complex waveforms with exceptional clarity. The compact 12.1-inch multi-touch display minimizes desk space while delivering superior measurement precision ideal for power electronics, automotive electronics, and embedded system applications.
Key Features
- 4 input channels
- 12-bit ADC resolution, up to 15 bits with enhanced resolution
- 350 MHz bandwidth (200 MHz, 500 MHz, and 1 GHz models available)
- Up to 10 GS/s sampling with Enhanced Sample Rate
- Long memory — up to 50 Mpts per channel
- HD4096 high definition technology for superior waveform clarity
- ±10V applied offset with high gain settings
- MAUI with OneTouch user interface
- Exceptional serial data tools and powerful measurement toolbox
- 16 digital channels available with -MS models
Applications
- Power electronics design and debugging
- Digital power management and power integrity analysis
- Automotive electronic systems development and testing
- Embedded and mechatronic system design
- High-precision analog measurement and characterization
Specifications
| Bandwidth | 350 MHz |
| Analog Channels | 4 |
| Digital Channels | None |
| Sampling Rate | 10 GS/s |
| Memory | 12.5 Mpts |
| Type | DSO |
| Vertical Resolution | 12 bit |
| Display Type | 12.1 TFT WXGA Color Touch |
| Series | HDO4000 Series |
