Tektronix MSO66B-TAA 6-BW-6000 Mixed Signal Oscilloscope

Overview

The Tektronix MSO66B-TAA 6-BW-6000 is a TAA-compliant 6-channel mixed signal oscilloscope designed for government and regulated buyers requiring Trade Agreements Act sourcing compliance. It delivers high bandwidth, low-noise signal fidelity, and flexible multi-channel analysis for modern high-speed embedded system design and debugging.

Key Features

• 6 FlexChannel analog inputs with 1 GHz probes included
• Up to 48 optional digital logic inputs via TLP058 logic probe
• 6 GHz analog bandwidth with 12-bit ADC (up to 16-bit in High Res mode)
• Real-time sample rate: 50 GS/s (2 channels), 25 GS/s (4 channels), 12.5 GS/s (>4 channels)
• 62.5 Mpoints standard record length, expandable to 1 Gpoint
• 15.6-inch high-definition touchscreen display (1,920 x 1,080) with capacitive touch
• 36 automated measurements and comprehensive trigger types including Visual Trigger
• Spectrum View frequency-domain analysis and FFT capabilities
• FastFrame segmented memory with >5,000,000 waveforms/second trigger rate
• Multiple connectivity options: USB, LAN, DisplayPort, DVI-I, VGA
• Remote control via e*Scope web browser interface
• Made in the USA

Applications

• Embedded systems design and debugging
• Three-phase power electronics analysis
• Automotive electronics testing
• Power supply design and characterization
• Power Integrity verification
• High-speed digital signal analysis

Included Accessories

• Six TPP1000 1 GHz passive probes (one per FlexChannel)
• Front cover with integrated accessory pouch
• Power cord
• Calibration certificate
• One-year warranty for instrument and included probes
