Siglent SDS1202X HD Mixed Signal Oscilloscope

Overview

The Siglent SDS1202X HD is a mixed signal oscilloscope with 200 MHz bandwidth and 2 GS/s maximum sample rate. It features 2 analog channels with 12-bit resolution and optional 16 digital channels for comprehensive signal analysis. The large 10.1-inch capacitive touchscreen provides intuitive control and excellent visibility for complex measurements.

Key Features

• 200 MHz bandwidth with 2 GS/s sample rate
• 12-bit analog-to-digital conversion with 70 µVrms noise floor
• 2 analog channels with optional 16 digital channels
• SPO technology with up to 120,000 waveforms/s capture rate (500,000 wfm/s in sequence mode)
• 256-level intensity grading and color temperature display modes
• Up to 100 Mpts record length with history waveform recording (up to 80,000 frames)
• Advanced triggering: edge, slope, pulse width, window, runt, pattern, video, and serial protocols
• Serial bus decoding for I2C, SPI, UART, CAN, LIN, CAN FD, and FlexRay
• 50+ automatic measurements with histogram, statistics, and gating capabilities
• Integrated 2 Mpts FFT and math functions
• Hardware-based mask test with custom mask editor
• USB Host/Device (USBTMC), LAN (VXI-11/Telnet/Socket), and remote web control
• Optional 25 MHz arbitrary waveform generator

Applications

• Electronics and circuit design validation
• Embedded systems debugging and troubleshooting
• Serial communication protocol analysis and verification
• Power supply and signal integrity analysis
• Signal processing and FFT analysis
• Educational and research laboratories

Included Accessories

• PP215 passive probes (1 per channel)
• USB cable
• Power cord
• Quick start guide
• Certificate of calibration
