Siglent SDS1102X HD Mixed Signal Oscilloscope

Overview

The Siglent SDS1102X HD is a 2-channel mixed-signal oscilloscope designed for high-resolution waveform capture and analysis. With a 100MHz bandwidth, 12-bit analog-to-digital converter, and 2GSa/s sampling rate, it provides superior noise performance with a 70µVrms noise floor. This oscilloscope is ideal for debugging complex electronic systems, signal integrity testing, and educational applications requiring precise waveform measurement and analysis.

Key Features

• 12-bit high-resolution analog-to-digital conversion with 2GSa/s sampling
• 100MHz bandwidth with 70µVrms noise floor
• 2 analog channels; optional 16 digital channels for mixed-signal analysis
• SPO technology with up to 120,000 waveforms/second capture rate (500,000 wfm/s in sequence mode)
• Up to 100Mpts maximum record length with segmented acquisition
• Multiple intelligent trigger modes: edge, slope, pulse width, pattern, serial bus, and more
• Serial protocol support: I2C, SPI, UART, CAN, LIN, FlexRay decode
• 50+ automatic measurements with statistical analysis (histogram, trend, tracking)
• 4 math traces with FFT, addition, subtraction, multiplication, division, integration, and more
• History waveform recording (up to 80,000 frames) and search/navigate functions
• Mask test with editor for user-defined test masks
• 10.1-inch capacitive touchscreen with multi-touch gesture support
• Built-in web server for remote control via LAN; SCPI command support
• Optional 25MHz arbitrary waveform generator

Applications

• Electronics debugging and troubleshooting
• Signal integrity and timing analysis
• Digital protocol analysis and debugging
• Power electronics and switching circuit analysis
• RF and microwave signal measurement
• Educational laboratories and training
• Embedded system development

Included Accessories

• USB cable
• PP510 passive probe (1 per analog channel)
• Quick start guide
• Certificate of calibration
• Power cord
