Rohde & Schwarz RTM3K-32M Digital Oscilloscope
Request a quote
Rohde & Schwarz RTM3K-32M is a 2-channel oscilloscope with 350 MHz bandwidth and mixed signal analysis (MSO) for high-frequency mixed-signal debugging.
Product details
| Model | RTM3K-32M |
| Manufacturer | Rohde & Schwarz |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz RTM3K-32M is a 2-channel mixed signal oscilloscope package combining the RTM3002 base unit, RTM-B223 bandwidth upgrade (350 MHz), and RTM-B1 mixed signal option. This configuration enables simultaneous analog waveform and digital logic state analysis at high frequencies for comprehensive troubleshooting of advanced mixed-signal designs.
Key Features
- 2-channel analog inputs with 350 MHz bandwidth
- Mixed Signal Option (RTM-B1) for digital logic analysis
- RTM3002 base oscilloscope with 100 MHz standard bandwidth
- RTM-B223 bandwidth upgrade extending capability to 350 MHz
- High-frequency mixed-signal measurement capability
- Advanced triggering on mixed-signal conditions
- Compact configuration for focused analysis
Applications
- High-frequency mixed-signal circuit debugging
- RF and digital interface analysis
- High-speed serial protocol measurements
- Advanced embedded system development
Specifications
| Bandwidth | 350 MHz |
| Analog Channels | 2 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 5 GS/s |
| Memory | 80 Mpts |
| Type | MSO |
| Vertical Resolution | 10 bit |
| Display Type | 10.1 WXGA Capacitive Color Touch |
| Series | RTM3000 Series |
| Alternate Product Number | 1335.8794P33 |
