Rohde & Schwarz RTM3002 Digital Oscilloscope

Overview

The Rohde & Schwarz RTM3002 is a 2-channel digital oscilloscope in the RTM3000 Series, delivering professional measurement capabilities for debugging and analyzing electronic systems. It combines a high-resolution 10-bit ADC, fast 5 GS/s sampling rate, and a large capacitive touchscreen display with integrated analysis tools including logic analyzer, protocol analyzer, and waveform generator.

Key Features

• 2 analog channels with 10-bit ADC (4× better resolution than 8-bit)
• 100 MHz base bandwidth, upgradeable to 200, 350, 500 MHz, or 1 GHz
• 5 GS/s sampling rate (interleaved), 2.5 GS/s on all channels
• 40 Msample standard memory, 80 Msample interleaved, up to 400 Msample with option
• 10.1-inch capacitive touchscreen (1280 × 800) with gesture support
• Outstanding 500 μV/div sensitivity with full measurement bandwidth
• Integrated logic analyzer, protocol analyzer, and waveform generator
• Fast 10-second boot time and Ethernet connectivity
• Three-year warranty

Applications

• Power supply analysis and switched-mode power supply debugging
• Serial protocol debugging (I2C, SPI, CAN, etc.)
• Signal integrity and transient analysis
• Frequency domain analysis and FFT measurements
• Long acquisition sequences and data capture

Included Accessories

• Power cord
• One RT-ZP05S probe per analog channel
