Rohde & Schwarz RTB2K-COM4 Mixed Signal Oscilloscope

Overview

The Rohde & Schwarz RTB2K-COM4 is a comprehensive mixed-signal oscilloscope package based on the RTB2004 platform. With 4 analog channels (expandable to 16 digital channels via the MSO option) and 300 MHz bandwidth, this instrument combines oscilloscope, logic analyzer, protocol analyzer, waveform generator, and digital voltmeter capabilities. The 10.1-inch capacitive touchscreen and intuitive interface make it ideal for educational labs, embedded design debugging, and production testing.

Key Features

• 4 analog channels with up to 16 digital channels via RTB-B1 MSO option
• 300 MHz bandwidth with 10-bit vertical resolution
• 10 Msample memory per channel, 20 Msample in interleaved mode
• Segmented memory: 160 Msample with history function
• 10.1-inch capacitive touchscreen with 1280 × 800 pixel resolution
• Integrated waveform and pattern generator (ARB) up to 50 Mbit/s
• Protocol triggering and decoding: I2C, SPI, UART, CAN/LIN, RS-232/RS-422/RS-485
• FFT frequency analysis with up to 128 kpoint resolution
• Mask test mode for automated pass/fail evaluation
• Digital voltmeter and frequency counter on each channel
• Built-in web server for MATLAB integration and remote access

Applications

• Embedded system design and debugging
• Serial protocol analysis and troubleshooting
• Power supply and switching analysis
• Educational laboratories and student training
• Production testing and quality assurance
• Frequency response analysis and Bode plot measurement

Included Accessories

• RTB2004 Oscilloscope with 300 MHz option
• RT-ZP03 passive voltage probes
• Power cord
• Software options: MSO, ARB Generator, protocol decode, history/segmented memory, frequency response analysis
