Rohde & Schwarz MXO38-2PK Mixed Signal Oscilloscope
Request a quote
Rohde & Schwarz MXO38-2PK is an 8-channel mixed signal oscilloscope with 200 MHz bandwidth, 5 Gsample/s sampling, 12-bit ADC, and the MXO3-PK1 application bundle.
Product details
| Model | MXO38-2PK |
| Manufacturer | Rohde & Schwarz |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz MXO38-2PK is an 8-channel mixed signal oscilloscope from the MXO 3 series, ideal for mid-range electronics testing and multi-channel signal analysis. This versatile instrument delivers 200 MHz bandwidth with 8 simultaneous analog channels in a compact form factor, providing an excellent balance of performance and value for design verification and troubleshooting applications.
Key Features
- 200 MHz bandwidth with up to 5 Gsample/s sample rate per channel
- 8 analog channels, expandable to 24 digital channels with optional MSO probes
- 12-bit ADC resolution at all sample rates; up to 18-bit with HD mode
- 125 Mpoints per channel standard memory, upgradeable to 500 Mpoints
- 4.5 million acquisitions per second update rate for real-time signal visibility
- Precise digital trigger sensitive enough to detect the smallest signal details
- 11.6 inch Full HD display with compact 5U height for rack mounting
- MXO3-PK1 application bundle including power analysis, protocol decoding, and arbitrary waveform generation
Applications
- Digital and analog circuit design verification
- Power supply and signal integrity analysis
- Serial protocol decoding and analysis (I2C, SPI, UART, CAN, LIN, ARINC 429)
- Automotive and aerospace electronics testing
- Time and frequency domain signal analysis
- Multi-channel mixed signal troubleshooting
Included Accessories
- 500 MHz 10X passive probe per channel
- Accessories bag
- Quick start guide
- Power cord
Specifications
| Bandwidth | 200 MHz |
| Analog Channels | 8 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 2.5 GS/s |
| Memory | 500 Mpts |
| Type | MSO |
| Vertical Resolution | 12 bit |
| Display Type | 11.6 Full HD Capacitive Touch |
| Series | MXO 3 Series |
| Alternate Product Number | 1335.2050P22 |
| Includes | Base Unit, 500 MHz 10X Passive Probe per channel, Accessories Bag , Quick Start Guide, Power Cord |
| Interface | USB, HDMI, LAN |
| Operating Temperature Range | 0-45°C |
| Risetime | 1.75 ns |
| Warranty | 3 Years |
