Rohde & Schwarz MXO34-2PK Mixed Signal Oscilloscope
Request a quote
Rohde & Schwarz MXO34-2PK mixed signal oscilloscope with 200 MHz bandwidth, 4 channels, 12-bit ADC, 5 Gsample/s, and included MXO3-PK1 application bundle.
Product details
| Model | MXO34-2PK |
| Manufacturer | Rohde & Schwarz |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz MXO34-2PK is a 4-channel mixed signal oscilloscope with 200 MHz bandwidth, 5 Gsample/s sample rate, and 12-bit ADC resolution. Part of the MXO 3 series, it combines reliable signal acquisition with the MXO3-PK1 application bundle for comprehensive protocol analysis, power measurement, and frequency domain testing in electronics development and troubleshooting.
Key Features
- 200 MHz bandwidth with 4 analog channels
- 5 Gsample/s sample rate with 125 Mpoints memory per channel, upgradeable to 500 Mpoints
- 12-bit ADC at all sample rates; 18-bit resolution available with HD mode
- 4.5 million waveforms per second update rate via MXO-EP ASIC technology
- Hardware-accelerated math, spectrum analysis, zone triggering, and mask testing
- 11.6" Full HD display with compact footprint; 5U rack-mount option
- 16-channel mixed signal capability with optional MSO probes
- Included MXO3-PK1 bundle: arbitrary waveform generator, power analysis, frequency response analysis, and multi-protocol decoding (I2C, SPI, UART, CAN, CAN FD, LIN, ARINC 429, MIL-STD-1553, MIPI)
Applications
- Embedded systems development and debug
- Mixed-signal circuit design validation
- Power integrity and power electronics analysis
- Automotive and aerospace protocol testing
- Frequency domain and spectral analysis
Included Accessories
- 500 MHz 10X passive probe per channel
- Accessories bag
- Quick start guide
- Power cord
Specifications
| Bandwidth | 200 MHz |
| Analog Channels | 4 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 2.5 GS/s |
| Memory | 500 Mpts |
| Type | MSO |
| Vertical Resolution | 12 bit |
| Display Type | 11.6 Full HD Capacitive Touch |
| Series | MXO 3 Series |
| Alternate Product Number | 1335.2050P12 |
| Includes | Base Unit, 500 MHz 10X Passive Probe per channel, Accessories Bag , Quick Start Guide, Power Cord |
| Interface | USB, HDMI, LAN |
| Operating Temperature Range | 0-45°C |
| Risetime | 1.75 ns |
| Warranty | 3 Years |
