RIGOL DS8104-R Digital Oscilloscope
Request a quote
RIGOL DS8104-R is a compact 4-channel digital oscilloscope featuring 1 GHz bandwidth, 10 GSa/s sampling, and 500 Mpts memory for signal analysis.
Product details
| Model | DS8104-R |
| Manufacturer | RIGOL |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The RIGOL DS8104-R is a compact 4-channel digital oscilloscope built on RIGOL's proprietary Phoenix chipset and UltraVision II platform. With 1 GHz analog bandwidth and 10 GSa/s real-time sampling, it delivers high-speed signal acquisition and analysis for engineering applications. The oscilloscope integrates multiple instrument modules for enhanced functionality.
Key Features
- 1 GHz analog channel bandwidth for high-speed signal measurement
- 10 GSa/s real-time sample rate with 500 Mpts standard memory depth
- 4 analog channels plus 1 external input channel
- Waveform capture rate exceeding 600,000 waveforms per second
- Multiple instrument modules: AWG, digital voltmeter, 6-digit counter, totalizer, and protocol analyzer
- Full digital trigger technology and full memory hardware measurement
- Low jitter with multiple-device synchronization support
Applications
- High-speed signal analysis and verification
- Protocol analysis and debugging
- Circuit design validation and troubleshooting
- Educational and research applications
Specifications
| Bandwidth | 1 GHz |
| Analog Channels | 4 |
| Sampling Rate | 10 GS/s |
| Memory | 500 Mpts |
| Type | DSO |
| Vertical Resolution | 8 bit |
| Series | DS8000-R Series |
