Keysight MXR604B Infiniium Real-Time Oscilloscope

Overview

The Keysight MXR604B Infiniium is a 4-channel real-time oscilloscope with 6 GHz bandwidth and 16 GSa/s sample rate across all channels. The higher bandwidth enables measurement of faster signal transitions, combined with a 10-bit analog-to-digital converter and hardware-accelerated analysis tools for advanced signal integrity and RF measurements.

Key Features

• 4 analog channels with 6 GHz bandwidth on each channel
• 16 GSa/s simultaneous sample rate on all channels
• 10-bit ADC resolution, upgradeable to 16 bits with high-resolution mode
• Flexible memory: 200 Mpts standard (upgradeable to 1.6 Gpts)
• Noise as low as 43 µV at 1 mV/div with 9.0 bits ENOB
• Intrinsic jitter as low as 118 fs
• 8-in-1 integrated tools: oscilloscope, logic analyzer, real-time spectrum analyzer, serial protocol analyzer, waveform generator, frequency response analyzer, digital voltmeter, and counter
• InfiniiScan advanced and zone triggering for signal integrity problems
• Fault Hunter automated analysis for extended test runs
• 15.6-inch full HD touchscreen with dual-display support
• Fully upgradeable and expandable to 4+16 channels

Applications

• High-frequency digital design verification
• RF and microwave circuit characterization
• Signal integrity and power integrity analysis
• High-speed serial protocol analysis
• Frequency response measurements

Included Accessories

• MXR604B 4-channel Infiniium oscilloscope
• Four N2873A 500 MHz passive probes
• Probe accessory pouch
• Front panel hard cover
• BNC calibration cable
• Keyboard and mouse
• Localized power cord
