Keysight MXR408B Infiniium Real-Time Oscilloscope

Overview

The Keysight MXR408B Infiniium is an 8-channel real-time oscilloscope with 4 GHz bandwidth and 16 GSa/s sample rate across all channels. The expanded channel count enables simultaneous monitoring of more signals, combined with a 10-bit analog-to-digital converter and hardware-accelerated analysis for signal integrity and design verification.

Key Features

• 8 analog channels with 4 GHz bandwidth on each channel
• 16 GSa/s simultaneous sample rate on all channels
• 10-bit ADC resolution, upgradeable to 16 bits with high-resolution mode
• Flexible memory: 200 Mpts per channel standard (upgradeable to 1.6 Gpts)
• Noise as low as 43 µV at 1 mV/div with 9.0 bits ENOB
• Intrinsic jitter as low as 118 fs
• 8-in-1 integrated tools: oscilloscope, logic analyzer, real-time spectrum analyzer, serial protocol analyzer, waveform generator, frequency response analyzer, digital voltmeter, and counter
• InfiniiScan advanced and zone triggering for signal integrity problems
• Fault Hunter automated analysis for extended test runs
• 15.6-inch full HD touchscreen with dual-display support
• Fully upgradeable to 6 GHz and expandable to 8+16 channels

Applications

• Multi-channel digital design verification
• Signal integrity and power integrity analysis
• RF and microwave measurements
• Serial protocol analysis and debugging
• Complex system characterization

Included Accessories

• MXR408B 8-channel Infiniium oscilloscope
• Eight N2873A 500 MHz passive probes
• Probe accessory pouch
• Front panel hard cover
• BNC calibration cable
• Keyboard and mouse
• Localized power cord
