Keysight MXR204B Infiniium Real-Time Oscilloscope

Overview

Keysight MXR204B is a premium 4-channel real-time oscilloscope with 2 GHz bandwidth and 16 GSa/s simultaneous sampling across all channels. Engineered for precision measurement, it delivers industry-leading signal integrity with low intrinsic jitter (118 fs), minimal noise (43 µV), and exceptional timebase accuracy for confident design verification and debugging.

Key Features

• 4 analog channels, 2 GHz bandwidth, 16 GSa/s sample rate
• 10-bit ADC with optional 16-bit high-resolution mode
• Intrinsic jitter as low as 118 fs, noise 43 µV at 1 mV/div
• 200 Mpts memory per channel (upgradeable to 400 Mpts or 1.6 Gpts)
• Timebase accuracy 8 parts per billion
• 8-in-1 integrated tools: oscilloscope, logic analyzer, real-time spectrum analyzer, serial protocol analyzer, waveform generator, frequency response analyzer, digital voltmeter, and counters
• InfiniiScan advanced triggering and zone triggering for detecting signal integrity issues
• Fault Hunter automated error detection (60 seconds to 48 hours test duration)
• History mode for reviewing up to 1,024 previous trigger events
• 15.6-inch full HD touchscreen with dual-display support
• Fully upgradeable to 6 GHz bandwidth and expandable to 4+16 channels

Applications

• High-speed digital and mixed-signal circuit design and debugging
• Serial protocol analysis and eye diagram measurement
• RF/microwave signal measurement with real-time spectrum analysis
• Production test automation with Fault Hunter
• Multi-channel waveform capture and trend analysis

Included Accessories

• 4× N2873A 500 MHz passive probes
• Probe accessory pouch
• Localized power cord
• Front panel hard cover
• BNC calibration cable
• Keyboard and mouse
