Keysight MSOX6002A Mixed Signal Oscilloscope
Mixed-signal oscilloscope with 1 GHz bandwidth (upgradable to 6 GHz), 2/16 channels, 20 GSa/s sampling rate, 450,000 waveforms/sec update rate, and optional eye diagram analysis.
Product details
| Model | MSOX6002A |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight InfiniiVision 6000 X-Series MSOX6002A is a 1 GHz mixed-signal oscilloscope (upgradable to 2.5, 4, or 6 GHz) designed for engineers who need high-speed signal acquisition and advanced analysis capabilities in a portable format. With 2 analog and 16 digital channels, the MSOX6002A delivers 20 GSa/s sampling rate, industry-leading 450,000 waveforms/sec update rate, and a large 12.1-inch capacitive touch screen designed for intuitive operation.
The 6000 X-Series combines powerful measurement capabilities with portability and ease of use. Advanced features like segmented memory, standard histogram and color-grade FFT, optional jitter and real-time eye diagram analysis, and voice control in 14 languages make it suitable for both general debugging and advanced signal integrity analysis.
Key Features
- 1 GHz bandwidth with upgradeable options to 2.5, 4, or 6 GHz
- 2 analog channels plus 16 digital channels with time-correlated triggering
- 20 GSa/s sampling rate and 4 Mpts maximum memory depth
- 450,000 waveforms/sec update rate for capturing infrequent events
- 12.1-inch capacitive multi-touch screen with voice control in 14 languages
- InfiniiScan Zone touch trigger for rapid signal isolation
- Standard histogram, color grade, and enhanced color FFT visualization
- Optional jitter and real-time eye diagram analysis for signal integrity
- 6 integrated instruments: Oscilloscope, logic analyzer, waveform generator, DVM, counter/totalizer, and serial protocol analyzer (optional)
- Three-year warranty with downloadable calibration certificate
Applications
- High-speed digital signal capture and analysis
- Signal integrity verification and eye diagram analysis
- Embedded system and FPGA development debugging
- Serial protocol trigger and decode (I2C, SPI, RS232, UART, optional)
- Power supply and switching behavior measurement
- General-purpose debugging with portable design
Included Accessories
- N2894A 700 MHz passive probe (10:1 attenuation) - one per analog channel
- N2756A 16-digital-channel MSO cable
- Localized power cord
- Front panel protective cover
- Certificate of Calibration with 2-year calibration interval (downloadable)
- User guide, service guide, and programmer's manual
- Multi-language support interface
Specifications
| Bandwidth | 1 GHz |
| Analog Channels | 2 |
| Digital Channels | 16 |
| Sampling Rate | 20 GS/s |
| Memory | 4 Mpts |
| Type | MSO |
| Vertical Resolution | 8 bit |
| Display Type | 12.1 Capacitive Color Touch |
| Series | 6000 X-Series |
| Interface | USB, LAN |
