Keysight MSOX4054G Mixed Signal Oscilloscope

Overview

The Keysight InfiniiVision MSOX4054G is a 4-analog/16-digital channel mixed signal oscilloscope designed for engineers who need integrated signal capture and protocol analysis. With 500 MHz bandwidth, 5 GSa/s sample rate, and 1 million waveforms per second update rate, it provides the performance required for general debugging, power analysis, and automotive and semiconductor development.

Key Features

• 4 analog + 16 digital channels
• 500 MHz bandwidth
• 5 GSa/s maximum sample rate
• 4 Mpts maximum memory depth
• 12.1-inch capacitive touch display
• 1,000,000 waveforms per second update rate
• 7 integrated instruments in one device
• Standard serial protocol analysis: I2C, SPI, RS232/422/485, UART, I2S, USB PD
• Optional protocol support: ARINC 429, CAN, CAN-dbc, CANFD, LIN, SENT, FlexRay, MIL-STD-1553, USB 2.0, CXPI, Manchester/NRZ
• Dual WaveGen, mask testing, FFT, histograms, and advanced waveform math
• Frequency response analysis and power analysis suite
• Zone trigger and segmented memory

Applications

• General signal debugging and design verification
• Power supply and control loop analysis
• Automotive system development and debugging
• Semiconductor device characterization
• Serial communication protocol troubleshooting

Included Accessories

• N2894A 700 MHz passive probe (10:1 attenuation) per analog channel
• N2756A 16-digital-channel MSO cable
• Localized power cord and front panel cover
