Keysight MSOX4052G Mixed Signal Oscilloscope

Overview

The Keysight MSOX4052G is a 2 analog and 16 digital channel mixed signal oscilloscope from the InfiniiVision 4000G X-Series. With a 500 MHz bandwidth, 5 GS/s maximum sample rate, and 4 Mpts memory depth, this higher-bandwidth model is ideal for engineers working with faster signals in power analysis, automotive systems, and semiconductor development applications.

Key Features

• 2 Analog / 16 Digital channels
• 500 MHz bandwidth
• 5 GS/s maximum sample rate
• 4 Mpts maximum memory depth
• 1,000,000 waveforms per second update rate
• 12.1-inch capacitive touch display with InfiniiScan Zone touch triggering
• 5-digit frequency counter
• Serial protocol analysis including I2C, SPI, RS232/422/485, UART, I2S, USB PD standard; optional ARINC 429, CAN, FlexRay, LIN, MIL-STD-1553, USB 2.0, and more
• Zone trigger, segmented memory, FFT, and advanced math functions
• Built-in help, dual waveform generator, mask testing, frequency response analysis
• 7 instruments integrated in 1 unit
• Standard USB 2.0, LAN, video output connectivity (GPIB optional)
• License upgradeable

Applications

• General debugging of digital and analog circuits at higher frequencies
• Power supply analysis and power electronics testing
• Automotive systems and embedded applications
• Semiconductor development and validation
• High-speed protocol analysis and serial bus troubleshooting

Included Accessories

• MSOX4052G 2+16 Channel Mixed Signal Oscilloscope
• N2894A 700 MHz passive probes (one per channel, 10:1 attenuation)
• N2756A 16-digital-channel MSO cable
• Localized power cord
• Front panel cover
• Calibration (downloadable soft copy)
