Keysight MSOX3034G Mixed Signal Oscilloscope
Request a quote
Keysight MSOX3034G is a 350 MHz mixed signal oscilloscope featuring 4 analog and 16 digital channels, 5 GS/s sampling, capacitive touch display, and 1 million waveforms/s update rate.
Product details
| Model | MSOX3034G |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight MSOX3034G is a 350 MHz mixed signal oscilloscope from the InfiniiVision 3000G X-Series, designed with an intuitive capacitive touch interface and compact form factor. It offers high-end measurement capabilities with industry-leading waveform update rate and advanced zone triggering, making it ideal for capturing and isolating elusive glitches and anomalies in complex electronic systems.
Key Features
- 350 MHz bandwidth with up to 5 GS/s sample rate
- 4 analog channels and 16 digital channels
- Up to 4M points memory depth
- Industry-leading 1 million waveforms per second update rate
- 8.5 inch capacitive touch display with intuitive interface
- Zone touch trigger for simplified advanced triggering
- 7-in-1 instrument integration: oscilloscope, frequency response analyzer, logic analyzer, protocol analyzer, function/arbitrary waveform generator, digital voltmeter, and counter
- Built-in 20 MHz function and arbitrary waveform generator
- Hardware-based serial protocol decoding: I2C, SPI, UART, I2S, USB PD
- Waveform and measurement histograms
- Mask limit and measurement limit testing
- Frequency response analysis (Bode plots)
- USB host, USB device, LAN, and VGA connectivity
Applications
- Embedded systems and microcontroller debugging
- Mixed-signal circuit design and verification
- Serial protocol analysis and decoding
- Frequency response and power analysis
- Video signal analysis (HDTV)
- General electronics development and troubleshooting
Included Accessories
- Passive probes N2843A (500 MHz, 10:1 attenuation, 1 per channel)
- Certificate of calibration
- Localized power cord
Specifications
| Bandwidth | 350 MHz |
| Analog Channels | 4 |
| Digital Channels | 16 |
| Sampling Rate | 5 GS/s |
| Memory | 4 Mpts |
| Type | MSO |
| Vertical Resolution | 8 bit |
| Display Type | 8.5 Capacitive Touch |
| Series | 3000G X-Series |
| Special Features | Function/Arbitrary Waveform Generator |
