Keysight MSOX3024G Mixed Signal Oscilloscope
Request a quote
Keysight MSOX3024G is a 200 MHz mixed signal oscilloscope with 4 analog and 16 digital channels, 5 GSa/s sample rate, and built-in 20 MHz waveform generator.
Product details
| Model | MSOX3024G |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight InfiniiVision 3000G X-Series MSOX3024G is a mixed signal oscilloscope combining high-end measurement technology in a compact form factor. It features 4 analog channels and 16 digital channels, offering industry-leading waveform update rates and advanced triggering capabilities for capturing and analyzing complex signals.
Key Features
- 200 MHz bandwidth
- 4 analog channels + 16 digital channels
- 5 GSa/s maximum sample rate
- 4M points memory depth
- 1,000,000 waveforms/second update rate
- 8.5-inch capacitive touch display
- Zone touch trigger for isolated signal analysis
- Built-in 20 MHz function/arbitrary waveform generator
- Multi-protocol trigger and decode: I2C, SPI, UART, I2S, USB PD
- Frequency response analysis (Bode plots)
- Segmented memory and waveform histograms
- USB host/device, LAN, and VGA connectivity
Applications
- Aerospace and defense: MIL-STD 1553 and ARINC 429 protocol analysis
- Automotive: Multi-serial bus decoding for powertrain and body control
- Power supply design and characterization
- USB 2.0 protocol analysis and debugging
- General digital circuit verification and signal analysis
Included Accessories
- Passive probes N2843A (500 MHz, 10:1 attenuation, 1 MĪ©, 11 pF) - 1 per channel
- Certificate of calibration
- Localized power cord
Specifications
| Bandwidth | 200 MHz |
| Analog Channels | 4 |
| Digital Channels | 16 |
| Sampling Rate | 5 GS/s |
| Memory | 4 Mpts |
| Type | MSO |
| Vertical Resolution | 8 bit |
| Display Type | 8.5 Capacitive Touch |
| Series | 3000G X-Series |
| Special Features | Function/Arbitrary Waveform Generator |
