Keysight MSOX3012G Mixed Signal Oscilloscope
Request a quote
Keysight MSOX3012G is a 100 MHz mixed signal oscilloscope with 2 analog and 16 digital channels, 5 GSa/s sample rate, built-in WaveGen, and 1,000,000 wfms/s update rate.
Product details
| Model | MSOX3012G |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight MSOX3012G is a mixed signal oscilloscope from the 3000G X-Series that combines high-end technology with user-friendly operation. With 100 MHz bandwidth, 2 analog channels, 16 digital channels, integrated 20 MHz waveform generator, and 1,000,000 waveforms per second update rate, it delivers comprehensive signal analysis for modern electronics development and troubleshooting.
Key Features
- 100 MHz analog bandwidth with 2 analog channels and 16 integrated digital channels
- Up to 5 GSa/s maximum sample rate with up to 4 Mpts memory depth
- 1,000,000 waveforms per second update rate with zone triggering
- 8.5-inch capacitive touch display with three-way interface (touch, buttons, or menu)
- Built-in 20 MHz function/arbitrary waveform generator (WaveGen)
- Hardware-based serial protocol decode (I2C, SPI, UART, I2S, USB PD) with simultaneous dual-bus decoding
- Waveform and measurement histograms
- Mask limit and measurement limit testing
- Frequency response analysis (Bode plots)
- Enhanced HDTV video analysis
- USB host and device, LAN, and VGA connectivity
- Industry-focused optional software (aerospace, automotive, power, USB)
Applications
- Embedded systems and microcontroller debugging
- Serial protocol verification and analysis
- Power supply and battery characterization
- Aerospace, automotive, and industrial embedded systems testing
- Mixed signal circuit development and validation
Specifications
| Bandwidth | 100 MHz |
| Analog Channels | 2 |
| Digital Channels | 16 |
| Sampling Rate | 5 GS/s |
| Memory | 4 Mpts |
| Type | MSO |
| Vertical Resolution | 8 bit |
| Display Type | 8.5 Capacitive Touch |
| Series | 3000G X-Series |
| Special Features | Function/Arbitrary Waveform Generator |
