Keysight MSOX2004A Mixed Signal Oscilloscope
Request a quote
Keysight MSOX2004A is a 70 MHz mixed-signal oscilloscope with 4 analog and 8 digital channels, 1 Mpts memory, and optional integrated function generator for circuit debugging.
Product details
| Model | MSOX2004A |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight MSOX2004A is a 70 MHz mixed-signal oscilloscope combining analog and digital channel capabilities in a compact, portable design. Built for field technicians, educators, and development engineers, it delivers high update rates and deep memory for real-time signal analysis and advanced debugging tasks.
Key Features
- 70 MHz bandwidth with 4 analog channels and 8 digital channels for mixed-signal analysis
- 1 GSa/s per channel sampling rate (2 GSa/s half-channel), 1 Mpts memory
- High update rate of 200,000 waveforms per second with MegaZoom IV technology
- 8.5-inch WVGA color display with twice the viewing area of competing models
- Optional 20 MHz WaveGen integrated function generator
- Hardware-accelerated mask testing and segmented memory for protocol analysis
- Multiple connectivity options: USB host/device, optional LAN, VGA, and GPIB
- Compact and lightweight: 8.5 lbs, 15 inches wide, less than 6 inches deep
- Fully upgradeable platform with five-year warranty
Applications
- Digital and mixed-signal circuit debugging and verification
- Serial protocol analysis and decoding (I2C, SPI, UART, and more)
- RF and analog signal measurement and characterization
- Educational training and lab demonstrations
- Portable fieldwork and system troubleshooting
Specifications
| Bandwidth | 70 MHz |
| Analog Channels | 4 |
| Digital Channels | 8 |
| Sampling Rate | 2 GS/s |
| Memory | 1 Mpts |
| Type | MSO |
| Vertical Resolution | 8 bit |
| Display Type | 8.5 WVGA |
| Series | 2000 X-Series |
