Keysight EDUX1052G Digital Oscilloscope

Overview

The Keysight EDUX1052G is a 50 MHz, 2-channel digital oscilloscope designed for educational institutions and training labs. Built on the same technology as Keysight's professional-grade instruments, it prepares students with industry-standard tools and workflows. The scope includes an integrated 20 MHz function generator, frequency response analyzer with Bode plots, and serial protocol decoding capabilities.

Key Features

• 2 channels with 50 MHz bandwidth
• 1 GS/s sample rate with 200k point memory depth
• 100,000 waveforms/sec update rate with MegaZoom IV technology
• Built-in 20 MHz WaveGen (function generator) with modulation (AM, FM, FSK)
• Frequency response analyzer for Bode gain and phase plots
• Integrated 3-digit DVM and 5-digit frequency counter
• Serial protocol analysis: I2C, UART, RS-232/422/485
• Waveform math: Add, subtract, multiply, divide, FFT, low-pass filter
• 7-inch TFT LCD WVGA display
• Built-in training signals and tutorials for students
• USB 2.0 and LAN connectivity; PathWave BenchVue software compatible

Applications

• Educational circuits and electronics labs
• Electrical engineering student training
• Physics lab measurements and signal analysis
• Circuit design validation and debugging
• Serial communication protocol development and testing

Included Accessories

• Two N2142A 75 MHz 10:1/1:1 switchable passive probes
• Power cord
• Certificate of Calibration
