Keysight DSOX4154G Digital Oscilloscope
Request a quote
Keysight DSOX4154G — 1.5 GHz, 4-channel oscilloscope with 5 GS/s sampling, 1,000,000 waveforms/sec, 12-inch touch display, and 7-in-1 analysis tools.
Product details
| Model | DSOX4154G |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight DSOX4154G is a versatile 4-channel digital oscilloscope from the InfiniiVision 4000G X-Series. It combines high-performance measurement capabilities with an intuitive capacitive touch interface, making it ideal for advanced debugging and industry-specific applications requiring 1.5 GHz bandwidth.
Key Features
- 1.5 GHz bandwidth with up to 5 GS/s maximum sample rate
- 4 Mpts maximum memory depth
- 1,000,000 waveforms per second update rate for reliable glitch capture
- 12.1-inch capacitive touch display with easy-to-use interface
- InfiniiScan Zone touch trigger for quick signal isolation
- Segmented memory and FFT analysis
- 5-digit integrated hardware frequency counter
- Serial protocol analysis: I2C, SPI, RS232/422/485, UART, I2S, USB PD (standard)
- Optional serial decoding: ARINC 429, CAN, LIN, MIL-STD-1553, FlexRay, CXPI, Manchester/NRZ
- Dual waveform generator, mask testing, and frequency response analysis
- 7 integrated instruments in one: oscilloscope, spectrum analyzer, protocol analyzer, waveform generator, frequency counter, voltmeter, and more
- License upgradeable for expanded capabilities
Applications
- High-speed electronics debugging and signal analysis
- Power supply rejection ratio and control loop response measurements
- Power analysis and conversion
- Automotive systems development and testing
- Semiconductor device characterization
- High-frequency protocol and signal integrity analysis
Included Accessories
- DSOX4154G 4-channel oscilloscope
- 4× N2894A 700 MHz passive probe (10:1 attenuation)
- Localized power cord
- Front panel cover
- Downloadable calibration certificate
Specifications
| Bandwidth | 1.5 GHz |
| Analog Channels | 4 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 5 GS/s |
| Memory | 4 Mpts |
| Type | DSO |
| Vertical Resolution | 12 bit |
| Display Type | 12.1 Capacitive Color Touch |
| Series | 4000G X-Series |
| Interface | USB,LAN |
