Keysight DSOX4034G Digital Oscilloscope
Request a quote
Keysight DSOX4034G is a 4-channel 350 MHz oscilloscope with 5 GSa/s sample rate, 4 Mpts memory, capacitive touch display, and 1 million waveforms/sec update rate.
Product details
| Model | DSOX4034G |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight DSOX4034G is a 4-channel digital oscilloscope from the InfiniiVision 4000G X-Series, designed for engineers requiring comprehensive signal analysis with simultaneous multi-channel measurements and integrated test capabilities. It combines intuitive touch-screen operation with advanced triggering and protocol analysis features, making it ideal for general debugging to industry-specific applications requiring multi-channel monitoring.
Key Features
- 4 analog channels with 350 MHz bandwidth
- Maximum sample rate of 5 GSa/s with 4 Mpts memory depth
- 1 million waveforms per second update rate for transient capture
- 12.1-inch capacitive touch display with InfiniiScan Zone trigger
- 7 integrated instruments: oscilloscope, waveform generator, FFT, logic analyzer, histogram, frequency counter, and mask testing
- Standard serial protocol analysis: I2C, SPI, RS232/422/485, UART, I2S, USB PD
- Optional serial decodes: CAN, LIN, ARINC 429, FlexRay, and others
- Built-in help and advanced waveform math
- License upgradeable for additional capabilities
Applications
- Multi-channel signal analysis and circuit debugging
- Power supply analysis with dedicated power analysis suite
- Automotive systems development and testing
- Semiconductor device characterization
- Protocol and serial data analysis
- Frequency response and stability measurements
Specifications
| Bandwidth | 350 MHz |
| Analog Channels | 4 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 5 GS/s |
| Memory | 4 Mpts |
| Type | DSO |
| Vertical Resolution | 12 bit |
| Display Type | 12.1 Capacitive Color Touch |
| Series | 4000G X-Series |
| Interface | USB,LAN |
