Keysight DSOX3054G Digital Oscilloscope

Overview

The Keysight DSOX3054G is a 500 MHz InfiniiVision 3000G X-Series digital oscilloscope designed to capture and isolate complex signals and elusive anomalies. With an intuitive capacitive touch interface, industry-leading waveform update rate of 1 million waveforms per second, and advanced zone triggering, it delivers real-time insight into signal behavior that competing instruments cannot match.

Key Features

• 500 MHz bandwidth with 4 independent channels
• 5 GS/s sampling rate with up to 4 M points memory depth
• 1,000,000 waveforms per second update rate powered by MegaZoom IV technology
• 8.5-inch capacitive touch display with three access methods: touch, front panel, and menu interface
• Zone Touch Trigger for isolating specific signal events
• Built-in 20 MHz function and arbitrary waveform generator
• Serial protocol triggering and decoding: I2C, SPI, UART, I2S, USB PD
• Waveform and measurement histograms
• Mask limit and measurement limit testing
• Frequency response analysis with Bode plots
• Integrated digital voltmeter and frequency counter
• USB host and device ports, LAN, and VGA connectivity for easy data export and remote control

Applications

• Electronic design verification and debug
• Serial protocol analysis and validation
• Power supply characterization
• Aerospace and defense testing with MIL-STD-1553 and ARINC 429 support
• Automotive embedded systems with power train and body control monitoring
• USB 2.0 signal integrity analysis
• General laboratory measurements and production test

Included Accessories

• Passive probes N2843A (500 MHz, 10:1 attenuation, 1 Megohm, 11 pF) — one per channel
• Certificate of calibration
• Localized power cord
