Keysight DSOX3052G Digital Oscilloscope

Overview

The Keysight DSOX3052G InfiniiVision Digital Oscilloscope is a 2-channel, 500 MHz instrument featuring a capacitive touch user interface and industry-leading 1 million waveforms per second update rate. This 3000G X-Series oscilloscope delivers high-end technology in a compact form factor with zone triggering, built-in WaveGen function generator, and 7-in-1 instrument integration for versatile test and measurement applications.

Key Features

• 500 MHz bandwidth with up to 5 GSa/s maximum sample rate
• 2 analog channels with up to 4 megapoint memory depth
• 1,000,000 waveforms per second update rate
• 8.5-inch capacitive touch display with zone touch triggering
• Three interface options: touch GUI, front panel controls, and pull-down menus
• Built-in 20 MHz function and arbitrary waveform generator with modulation
• Serial protocol decoding: I2C, SPI, UART, I2S, and USB PD trigger and decode
• Waveform and measurement histograms
• Mask limit and measurement limit testing
• Frequency response analysis with Bode plots
• Enhanced HDTV video analysis
• USB host, USB device, LAN, and VGA connectivity

Applications

• Mixed-signal design verification and debugging
• Serial communication bus analysis
• Power supply and device characterization
• Embedded systems development and testing

Included Accessories

• N2843A passive probes (500 MHz, 10:1 attenuation, 1 per channel)
• Certificate of calibration
• Localized power cord
