Keysight DSOX3034G Digital Oscilloscope

Overview

The Keysight DSOX3034G InfiniiVision 3000G X-Series oscilloscope delivers high-end technology in a compact form factor. With intuitive touch interface, industry-leading 1 million waveforms per second update rate, and zone trigger capabilities, it captures and isolates elusive glitches and anomalies. The 350 MHz bandwidth, 4 channels, and up to 5 GSa/s sampling provide comprehensive signal capture with three user interface modes: touch GUI, traditional front panel controls, or Windows-like menus.

Key Features

• 350 MHz bandwidth with 4 analog input channels
• Up to 5 GSa/s maximum sample rate with 4 Mpts memory depth
• 1 million waveforms/s update rate powered by MegaZoom IV smart memory
• 8.5-inch capacitive touch display with zone touch triggering
• 7-in-1 instrument integration: oscilloscope, waveform generator, protocol analyzer, frequency response analyzer, DVM, counter, and digital channels
• Built-in 20 MHz function/arbitrary waveform generator
• I2C, SPI, UART, I2S, and USB PD protocol trigger and decode
• Waveform and measurement histograms with mask and measurement limit testing
• USB host, USB device, LAN, and VGA connectivity with mobile device monitoring support

Applications

• Aerospace and defense serial bus analysis (MIL-STD-1553, ARINC 429)
• Automotive serial bus decode and analysis for powertrain and body control
• Power supply characterization and automated measurements
• USB 2.0 protocol triggering and analysis
• General-purpose multi-signal analysis and troubleshooting

Included Accessories

• Passive probes N2843A, 500 MHz, 10:1 attenuation (1 per channel)
• Certificate of calibration
• Localized power cord
