Keysight DSOX3024G Digital Oscilloscope
Request a quote
Keysight DSOX3024G is a 4-channel, 200MHz digital oscilloscope with 5GS/s sampling, 4Mpts memory, built-in waveform generator, and intuitive touch interface.
Product details
| Model | DSOX3024G |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight InfiniiVision 3000G X-Series DSOX3024G is a 4-channel, 200MHz digital oscilloscope designed for engineers and technicians who need to capture and isolate complex signal behaviors. With a capacitive touch display, industry-leading 1 million waveforms per second update rate, and integrated analysis tools, the DSOX3024G delivers exceptional visibility into signal details and supports advanced debugging and characterization tasks.
Key Features
- 4 channels with 200MHz bandwidth
- Up to 5 GSa/s maximum sample rate
- 4M points memory depth for extended capture windows
- 1,000,000 waveforms per second update rate for capturing rare events
- 8.5-inch capacitive touch display with intuitive interface
- Built-in 20MHz function and arbitrary waveform generator
- Zone touch triggering for precise signal isolation
- Serial protocol trigger and decode: I2C, SPI, UART, I2S, USB PD
- Frequency response analysis (Bode plots)
- Waveform and measurement histograms
- USB host and device ports, LAN and VGA connectivity
Applications
- Electronics design and debugging
- Serial communication protocol analysis
- Power supply characterization
- Embedded system development
- Educational laboratory work
Included Accessories
- Passive probes N2843A, 500 MHz, 10:1 attenuation (1 per channel)
- Certificate of calibration
- Localized power cord
Specifications
| Bandwidth | 200 MHz |
| Analog Channels | 4 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 5 GS/s |
| Memory | 4 Mpts |
| Type | DSO |
| Vertical Resolution | 8 bit |
| Display Type | 8.5 Capacitive Touch |
| Series | 3000G X-Series |
| Special Features | Function/Arbitrary Waveform Generator |
