Keysight DSOX2014A Digital Oscilloscope
Request a quote
Keysight DSOX2014A is a 100 MHz, 4-channel digital oscilloscope with 1 Mpts memory, 200,000 waveforms/sec update rate, and 8.5" WVGA display.
Product details
| Model | DSOX2014A |
| Manufacturer | Keysight |
| Category | Digital Oscilloscopes |
| Availability | Made to order |
Description
Overview
The Keysight InfiniiVision DSOX2014A is a 100 MHz, 4-channel digital oscilloscope designed for engineers and technicians who need reliable signal analysis and circuit debugging. It features a large 8.5-inch color display, fast waveform capture at 200,000 updates per second, optional integrated instruments, and full upgradeability to meet evolving test requirements.
Key Features
- 100 MHz bandwidth with 4 analog input channels
- 1 Mpts memory per channel for extended signal capture
- 8.5" WVGA color display with twice the viewing area of competing scopes
- 200,000 waveforms per second update rate for responsive signal visualization
- 1 GSa/s per channel, 2 GSa/s in 1-channel mode for high-speed sampling
- Integrated waveform math, FFT analysis, and MegaZoom IV technology
- Optional 20 MHz WaveGen function generator for signal generation
- Optional hardware serial protocol triggering and decoding
- Upgradeable to MSO capability with optional digital channel module
- USB, optional LAN, VGA, and GPIB connectivity
- Five-year warranty and BenchVue software for test automation
Applications
- Multi-channel signal analysis and comparison
- Troubleshooting and debugging analog circuits
- Educational training in electronic measurement techniques
- General-purpose oscilloscope applications and signal visualization
Specifications
| Bandwidth | 100 MHz |
| Analog Channels | 4 |
| Digital Channels | Upgrade Required |
| Sampling Rate | 2 GS/s |
| Memory | 1 Mpts |
| Type | DSO |
| Vertical Resolution | 8 bit |
| Display Type | 8.5 Touch |
| Series | 2000 X-Series |
