RIGOL RP1004C Current Probe
Request a quote
RIGOL RP1004C is a high-bandwidth current probe with DC to 100MHz frequency response, capable of measuring up to 50A peak with Hall effect sensor technology.
Product details
| Model | RP1004C |
| Manufacturer | RIGOL |
| Category | Current Probes |
| Availability | Made to order |
Description
Overview
The RIGOL RP1004C is a high-bandwidth current probe offering DC to 100MHz frequency response for precise measurement of high-frequency current signals. With a peak current capacity of 50A, it incorporates a thin film Hall effect sensor for highly accurate current detection. The compact design enables reliable measurement of low current levels while providing protection against input overload.
Key Features
- Frequency response: DC to 100MHz
- Peak current capacity: 50A
- Thin film Hall effect sensing element
- Compact design for low current measurements
- Overload protection with easy protection function
- Direct BNC connection to oscilloscope or measuring instrument
Applications
- High-frequency waveform analysis and measurement
- Power supply and switching circuit current monitoring
- High-frequency current detection
- Component and circuit validation
Included Accessories
- User Guide
- Probe Case
Specifications
| Maximum Current | 50 A |
| Input Coupling | AC/DC |
| Bandwidth | 100 MHz |
| Cable Length | 1 m |
| Series | RP100XC Series |
| Maximum Wire Size | 5 mm |
| Peak Current | 50 A |
| Power Supply | 12 V |
| Probe Length | 1.5 m |
