RIGOL RP1003C Current Probe
Request a quote
RIGOL RP1003C is a wideband current probe with DC to 50MHz bandwidth, capable of measuring up to 50A peak using Hall effect sensor technology.
Product details
| Model | RP1003C |
| Manufacturer | RIGOL |
| Category | Current Probes |
| Availability | Made to order |
Description
Overview
The RIGOL RP1003C is a wideband current probe featuring DC to 50MHz bandwidth for high-frequency current measurements. With a peak current capacity of 50A, it uses a thin film Hall effect sensor element for highly accurate current detection. The compact design allows for precise measurement of low current levels while protecting against excessive input.
Key Features
- Frequency response: DC to 50MHz
- Peak current capacity: 50A
- Thin film Hall effect sensing element
- Compact design for low current measurements
- Overload protection with easy protection function
- Direct BNC connection to oscilloscope or measuring instrument
Applications
- Waveform measurement and analysis in high-frequency circuits
- Power supply current monitoring
- High-frequency current detection
- Device and component testing
Included Accessories
- User Guide
- Probe Case
Specifications
| Maximum Current | 50 A |
| Input Coupling | AC/DC |
| Bandwidth | 50 MHz |
| Cable Length | 1 m |
| Series | RP100XC Series |
| Maximum Wire Size | 5 mm |
| Peak Current | 50 A |
| Power Supply | 12 V |
| Probe Length | 1.5 m |
