Mitutoyo 568-957 Digimatic Snap-Open Bore Gage
Request a quote
Mitutoyo 568-957 — precision bore gage with 25-50mm range, 330° rotatable display, GO/NO-GO function, ABSOLUTE encoder, and SPC data output.
Product details
| Model | 568-957 |
| Manufacturer | Mitutoyo |
| Category | Bore Gages |
| Availability | Made to order |
Description
Overview
The Mitutoyo 568-957 Digimatic Snap-Open is a digital bore gage with a measurement range of 25 to 50 mm. It features a rotatable display unit and advanced encoder technology for reliable, error-free readings. The instrument is designed for efficient measurement of medium to large bores with the ability to reach deep blind holes.
Key Features
- Measurement range of 25 to 50 mm
- Large LCD digits (8.5 mm height) for easy, error-free reading
- 330-degree rotatable display for convenient viewing at any angle
- GO/NO-GO judgment function for quick pass/fail assessment
- ABSOLUTE linear encoder technology eliminates over-speed errors
- TiN-coated measuring contact points for durability and impact resistance
- SPC data output for computer-based measurement recording
- Snap-open design allows measurement to the bottom of blind holes
Applications
- Precision bore measurement and inspection
- Quality control and GO/NO-GO testing
- Deep bore and blind hole measurement
Included Accessories
- Setting rings for origin point setting (177-139, 177-290)
- Wooden fitted case
Specifications
| Measurement Range | 25 to 50 mm |
| LCD Digit Height | 8.5 mm |
| Display Rotation | 330 degrees |
| Contact Material | TiN-coated |
| Encoder Type | ABSOLUTE linear |
| Functions | GO/NO-GO judgment, SPC data output |
| Accessories | Setting rings, wooden case |
