Keysight DP0010A Differential Active Probe
Request a quote
Keysight DP0010A is a 250 MHz differential active probe with ±42 V range and 1.7 MΩ impedance, ideal for motor drives and automotive measurements.
Product details
| Model | DP0010A |
| Manufacturer | Keysight |
| Category | Active & Differential Probes |
| Availability | Made to order |
Description
Overview
Keysight DP0010A is a 250 MHz differential active probe from the DP001xA Series, designed for general-purpose differential signal measurements in power-related applications. The probe provides excellent accuracy for motor drive measurements, automotive differential bus signal acquisition, and high-speed digital system design. Its 1.7 MΩ input impedance and 1.5 pF capacitance minimize circuit loading, making it ideal for precision measurements in sensitive circuits.
Key Features
- 250 MHz bandwidth for high-speed differential measurements
- Dual attenuation ranges: ±4.2 V (17:1) and ±42 V (85:1)
- Input impedance: 1.7 MΩ || 1.5 pF for minimal loading
- 1.3-meter cable length for flexible measurement setup
- Compatible with Keysight InfiniiVision and Infiniium oscilloscope series
- AutoProbe interface for automatic scope detection and configuration
Applications
- Motor drive control signal measurements
- Automotive differential bus signal acquisition
- High-speed digital system characterization
- Power electronics circuit design verification
Included Accessories
- Socketed Y-lead pair (2 pieces)
- Solder-in Y-lead pair (2 pieces)
- 90° socketed ground lead (1 piece)
- Micro circuit hook test clips (2 pieces)
- Adjustable probe stand (2 pieces)
- Probe tip savers (2 pieces)
- Straight pins (10 pieces)
- Hard plastic carrying case
Specifications
| Bandwidth | 250 MHz |
| Attenuation | 17X, 85X |
| Input Capacitance | 1.5 pF |
| Maximum Input Voltage | 30 V |
| Input Impedance | 1.7 MΩ |
| Interface | AutoProbe1 |
| Cable Length | 1.3 m |
| Series | DP001xA Series |
| Lead Length | 1.3 m |
| Operating Temperature Range | 5 to 40°C |
| Risetime | 1.35 ns |
| Series Compatibility | 3000T X Series, 4000 X Series, 6000 X Series, EXR Series, MXR Series, S Series, UXR Series, V Series, Z Series, Q Series, 90000 X Series. |
| Type | Differential Probe |
