PIE 520B-S Single Thermocouple Source
Request a quote
PIE 520B-S is a portable thermocouple source for Type S calibration with ±0.015% mV accuracy, 0.1°C/F resolution, and 45-hour battery life.
Product details
| Model | PIE 520B-S |
| Manufacturer | PIE |
| Category | Temperature Probes & Sensors |
| Availability | Made to order |
Description
Overview
The PIE 520B-S is a single thermocouple source designed for Type S thermocouple calibration. It features an adjustable temperature output with high accuracy and long battery life, making it ideal for field and laboratory calibration work.
Key Features
- Type S thermocouple source with ±(0.015% of mV Setting + 0.009mV) accuracy
- Adjustable temperature output in 0.1°C or 0.1°F increments
- EZ-Dial knob for easy adjustment with 0.1° resolution
- EZ-Check switch for 0% and 100% span adjustments
- 45-hour battery life on standard AA alkaline batteries
- Protected to 60V
- Lightweight, rugged design with easy battery access
Applications
- Thermocouple instrument calibration
- Temperature probe verification
- Field temperature testing
Specifications
| Thermocouple Type | Type S |
| mV Accuracy | ±(0.015% of mV Setting + 0.009mV) |
| Temperature Resolution | 0.1°C or 0.1°F |
| Typical Temperature Accuracy | ±0.35°C (0.63°F) for Type K |
| Temperature Adjustment | Selectable 0.1°C or 0.1°F steps |
| Span Adjustment | 0%, 50%, and 100% via EZ-Check switch |
| Battery Type | AA Alkaline |
| Battery Life | 45 hours typical continuous use |
| Overvoltage Protection | 60V |
