PIE 520B-P Thermocouple Source
Request a quote
PIE 520B-P thermocouple source for Type P with ±(0.015% of mV + 0.009mV) accuracy, adjustable 0.1°C/°F output, and 45-hour battery life.
Product details
| Model | PIE 520B-P |
| Manufacturer | PIE |
| Category | Temperature Probes & Sensors |
| Availability | Made to order |
Description
Overview
The PIE 520B-P is a portable thermocouple source designed for calibrating and testing Type P thermocouples. It provides precise voltage and temperature output with exceptional battery life, making it ideal for field calibration work and laboratory applications.
Key Features
- Type P thermocouple support with selectable output in °C or °F
- Accuracy of ±(0.015% of mV Setting + 0.009mV)
- EZ-Dial™ knob for easy 0.1°C or 0.1°F adjustments
- EZ-Check™ switch for 0% and 100% span verification
- 45-hour battery life with standard AA alkaline batteries
- Lightweight and rugged construction
- 60V overvoltage protection
Specifications
| Thermocouple Type | P |
| Accuracy (mV Setting) | ±(0.015% + 0.009mV) |
| Temperature Adjustment Resolution | 0.1°C or 0.1°F |
| Power Supply | Standard AA Alkaline Batteries |
| Battery Life | 45 hours (typical continuous usage) |
| Overvoltage Protection | 60V |
